A Look Back: The Colt New Service Revolver

A Look Back: The Colt New Service Revolver

As early as 1857 Colt was working on the concept of a double-action revolver. The company even patented a design for a trigger-cocking revolver, but this design never saw production. William Mason, a patternmaker and engineer at Remington, patented a swing-out cylinder with a star-type ejector operated by a rod in the center of the cylinder that ejected all of the cases in the cylinder in 1865, patent number 51,117. Mason came to work at Colt in 1866 from Remington, and began a 16-year stint as one of the company’s leading engineers and gunsmiths. He, along with Charles Richards, developed the Richards Mason Conversion of percussion revolvers in 1871. Mason and Richards are also credited with engineering a topstrap for additional strength on the Model 1871-72 “Open Top” revolver that became the famous 1873 Peacemaker. A few years later he patented a double-action design that became the Model 1877 Lightning.

Later Mason teamed with Carl J. Ehbets to combine the double-action revolver with a swing-out cylinder and integral star-type ejector. Though he left Colt in 1882, Mason gets credit for helping develop the Colt Model 1889 double-action revolver. This was the first double-action revolver with what would become the familiar profile of such revolvers—one with a flatter and more lightweight recoil shield, a swing-out cylinder operated by a sliding thumb latch on the left side of the frame and a grip frame contour that transferred recoil more directly into the shooting hand. A year later the U.S. Navy adopted the .38-cal. Model 1889 revolver, and three years after that the Army adopted it.

Shooters, lawmen and especially the Army were simply not satisfied with the .38 Long Colt cartridge. A 150-gr. lead round-nose bullet at 777 fps generates a paltry 210 ft.-lbs. of energy at the muzzle and can’t be depended upon to stop an assailant, be it a Moro tribesman or a critter larger than a rabbit. So in 1898 Colt debuted a new large-frame double action revolver chambered in the more popular and effective cartridges like .38-40, .44-40, .44 Russian, .44 Spl. and .45 Colt. Colt christened the revolver as the New Service. Barrel lengths ranged from 4" to 7 1/2". Stocks were made of rubber or walnut, and the metal was available as blued or nickel plated. To foreign markets, Colt chambered the New Service in .450 Boxer, .455 Webley, and .476 Enfield.

The New Service was an immediate hit. Backcountry travelers and law officers liked the robust revolver and its hard-hitting cartridges. By 1909 Colt had made some lockwork changes, replacing several of the smaller leaf springs with coil springs, thus minimizing breakages. A bar of steel was added between the hammer and the frame—Colt called it the “Colt Positive Lock”—to prevent unwanted discharges in the event that the hammer was struck or the gun dropped. The Army adopted this Model 1909 revolver chambered in .45 Colt with a case that had a slightly larger rim to ensure extraction. After a small change in the grip profile, the Marine Corps ordered a small quantity of this iteration of the New Service.

Because of the abject failure of the .38 Long Colt cartridge, and the limited manufacturing capabilities in turning out the 1911 pistol, the New Service was drafted as a military pistol during World War I. The Model 1917 Colt was similar to the 1917 Smith & Wesson—a large-frame, fixed-sight revolver chambered in .45 ACP and issued with half-moon clips to facilitate extraction from a revolver’s cylinder. At first the cylinders were bore straight through, and these revolvers could not fire a cartridge without the half-moon clips. Sometime later a “lip” was machined into the cylinder allowing the case to headspace on its mouth as it does in the 1911 pistol. The cylinders of these latter 1917s were also machined at the rear to accommodate the half-moon clips. This modification was done to allow the 1917 to be fired whether the soldier had half-moon clips or not.

By 1918 Colt had sent 151,700 Model 1917 revolvers to the Army. Between the world wars the 1917 revolvers—both Smith & Wessons and Colts—lay in storage, though some were used by federal agencies, including the Border Patrol, Post Office, Justice and Treasury Departments. During this time Colt dropped .44 Russian, .450 Boxer, and .476 Enfield chamberings and added the .38 Special. In 1936 the .357 Magnum was added to the New Service stable of cartridges.

The New Service found favor outside the United States. In Canada, the New Service replaced the less-than-stellar Enfield Mk II revolver. The hoplophobic Brits pined for New Service revolvers during World War I. Of course, subjects of the king could only go so far with this American gun stuff and insisted on their revolvers being chambered for the proper British .455 Webley cartridge. Once hostilities ceased, the Brits could not get these revolvers back to the U.S. fast enough, hence the surplus market of New Services chambered in .455 Webley. Even the Cuban government purchased New Service revolvers chambered in .45 Colt before and after World War I to issue its army and the Guardia Rurales.

When World War II rolled around, as is typical, gun warehouses were raided for anything that shoots, and some 96,000-plus Model 1917 Colts were reconditioned and issued to military police and training units. Production of the New Service ceased in 1946 with about 357,000 revolvers made.

Colt also made a target version of the New Service. Manufactured from 1900 until 1940, it featured adjustable front and rear sights atop a flat-top frame and was chambered in .44 Special, .44 Russian, .45 Colt, and .45ACP. Most were made with a 7 1/2-inch barrel, but a few were assembled with 6-inch barrels. The trigger and backstrap were checkered on the target version. Grips were black rubber until 1913, then checkered walnut with an inlaid silver medallion until the end of production. Nickel-finished New Service Targets are very rare, but a few were made. A very highly sought after variant, the New Service Shooting Master, was a high-grade variation of the Target. Made from 1932 until 1940, the Shooting Master exemplified some of the finest gunmaking and finishing craftsmanship to ever come from Colt. It had a 6-inch barrel and was chambered in .38 Spl., .357 Mag., .44 Spl., .45 Colt, and .45 ACP.

Colt did not offer a shrouded ejector rod until the 1970s on any of its double-action revolvers. The New Service was Colt’s only large-frame double-action revolver until the Anaconda was introduced in 1990. Like all vintage Colts, the New Service commands quite a premium to collectors of such art that shoots. A raw-boned shooter New Service can fetch right around a grand, while more pristine examples go for two, three or more times that. Every time I get a chance to visit with someone from Colt—rare these days—I urge them to offer a limited run of the New Service revolver. It’s too good of a gun to let go away. But they don’t listen to me.
