Getting To The Bottom Of “LOCK” and “LOAD”

There have been dozens of letters and e-mails on the topic of “Lock and Load.” While we cannot say what individual range commands were on every military and civilian range for nearly a century, we can rely on the printed War Dept. and Dept. of the Army sources.


There are differences in the terms used to define and explain rifle operation and the range commands used in marksmanship training and firing for record. For example, FM 23-5 U.S. Rifle Caliber .30, M1 in “Section II: How The Rifle Works” defines “(3) Locking—locking the bolt in the receiver.” And then it defines “(5) Unlocking—unlocking the bolt from the receiver.” It is explained as “c. Locking. When the bolt is all the way forward, the rear camming surface in the hump of the operating rod forces the operating lug of the bolt downward, causing the bolt to rotate clockwise. The bolt is locked by the locking lugs on both sides of the bolt, engaging locking recesses in the receiver.”


But that applies only to the description of the rifle’s operation. Range commands and usage are different matters entirely. The earliest reference I found in U.S. military literature regarding “lock” and “load” was from the War Department Basic Field Manual, Volume III, Basic Weapons (1932). There are perhaps earlier uses of these terms, but in our reference library I was unable to find previous instances. In the section describing Rapid Fire “(b) When all is ready in the pit, a red flag is displayed at the center target. At that signal the officer in charge of the firing line commands: LOAD. The rifles are then loaded and locked.” Remember, these range instructions were for the U.S. M1903 and the U.S. M1917 rifles, both bolt-actions that did not allow the bolt to be manipulated with the safety engaged, or “locked.”


In FM 23-6, Basic Field Manual U.S. Rifle Caliber .30, M1917 October 1943, it gives the definition of “lock” as it pertains to the safety on the U.S. M1917. “f. Safety device—To set at safe, turn the safety lock to the rear as far as it will go. This locks the bolt handle in position, and lifts the sear notch off the sear nose. To unlock, turn safety lock to the front.”


For the Sustained Fire marksmanship instruction, FM 23-6 gives the following: “2. When all is ready in the pit, a red flag is displayed at the center target/ At that signal the officer in charge of the firing line commands : LOAD, LOCK.” … “4. All being ready on the firing line, the officer in charge commands: READY ON THE FIRING LINE. Rifles are unlocked and each rifleman stands relaxed and prepared to assume the prescribed position when his target appears.”


In FM 23-5 U.S. Rifle Caliber .30, M1 put out by the Departments of the Army and the Air Force in October 1951, a clear definition is given to “lock” and “unlock” pertaining to operation of the manual safety: “41. To Set The Rifle At Safe … The loaded rifle must be kept locked until you are ready to shoot. To lock the rifle, snap the safety to its rear position inside the trigger guard … To unlock the rifle, push the safety to its forward position.”


But in answer to the original member inquiry, certainly during the World War II era, “LOCK” was referring to the safety of the M1 Garand.


Share |

Comments

ADD YOUR COMMENT

Enter your comments below, they will appear within 24 hours


Your Name


Your Email


Your Comment

3 Responses to Getting To The Bottom Of “LOCK” and “LOAD”

Old Corps Marine wrote:
October 16, 2012

Command: Lock and load! 1. Engage safety by pushing rearward. 2. Reach down to cartridge belt and retrieve either a single round or a clip with two rounds. 3. Insert round or rounds in magazine and let bolt go home. 4. Stand facing the targets. 5. Upon appearance of targets, assume position appropriate for course of fire. 6. Push safety forward with trigger finger and commence firing. 7. Upon completing course of fire apply the safety once more. 8. Remain in position until RSO gives follow along command. If firing from sitting, kneeling or prone position, remove sling from arm and prepare to receive scores and mark score book.

Old Corps Marine wrote:
October 15, 2012

If you were at Perris Island during the time the M-1 Garand was the issue weapon, upon the command, "lock and load," your coach or the RSO had better hear the click of your safety moving from fire to safe otherwise at the very least your ancestry and certainly your mental acuity would be subject to critical comment. Inasmuch as the M-1's were always carried with the bolt locked back on the range, it wouldn't make much sense to issue a command to move the bolt to the rear. Again, had your bolt not been to the rear etc etc etc. After you moved the safety to the rear position, you either loaded a single round or two rounds, depending upon what course you were firing, got ready and when the targets appeared, put your rifle to your shoulder, moved the safety to the fire position and fired your first shot for the course.

Alex D. wrote:
October 15, 2012

This explains nothing. So what is the sequence? Put the rifle on safe, then load, then off safe, then fire? If so, why don't you say so. If not, what then?
